Watching your pond water level drop can immediately send your mind to the worst-case scenario.
There must be a hole in the liner.
Before you start moving rocks, draining the pond or planning to replace the liner, there is some good news: a puncture is only one possible source of water loss.
Ponds can lose water from collapsed edges, plumbing connections, streams, waterfalls, plant roots, splash and other areas that may be much easier to correct than a damaged liner.
The fastest way to find a pond leak is usually not to start searching everywhere at once. Instead, narrow down which part of the pond system is losing water.
For a lined pond, that process often starts with one simple step: turn off the pump.
First, Make Sure Your Pond Is Actually Leaking
Not every drop in water level indicates a leak.
Evaporation and splash naturally remove water from a pond. Waterfalls, fountains and streams can increase water loss, especially when water splashes beyond the liner.
Weather also affects evaporation, which means the amount of water your pond loses naturally will not remain exactly the same throughout the year.
If the water loss seems excessive or suddenly changes from what you normally see, it is time to start troubleshooting.
Before assuming the liner has failed, look around the pond for clues. Unusually wet soil, consistently damp areas or patches of grass that are noticeably greener than their surroundings may point toward escaping water.
The Most Common Pond Leak May Not Be a Hole
When people hear "pond leak," they often picture a punctured liner.
In lined ponds, one of the most common problems EasyPro encounters is actually a collapsed edge.
When a pond is constructed, liner extends up and around the perimeter before rocks and landscaping are installed. Over time, the soil and rock around the pond can settle. As they move, they may pull a section of liner downward.
If that section drops below the normal water level, pond water can begin seeping over the edge.
The liner itself may be completely intact.
Collapsed edges can be especially frustrating because the escaping water may disappear into the surrounding soil without creating an obvious stream or puddle.
Before searching for a tiny hole somewhere underwater, walk the entire perimeter and inspect the liner elevation.
Look closely around waterfalls, streams and areas where the surrounding ground has settled.
Plants Can Pull Water Out of a Pond, Too
Vegetation around a pond can create another easily overlooked source of water loss.
Roots and plants may grow over the liner edge and create a path for water to move outside the pond. This is sometimes referred to as wicking.
A pond that has operated without problems for years can develop this issue as surrounding vegetation matures.
When checking the pond perimeter, pay attention to plants that have spread across or beyond the liner edge. Trimming vegetation and restoring the liner to the correct elevation may solve the problem without requiring any liner repair.
Step 1: Turn Off the Pond Pump
For a lined pond with a pump, the pump-off test is one of the best places to begin.
Turning off the pump temporarily separates the main pond from many other components in the system.
When the pump is running, water may travel through:
-
Plumbing
-
Fittings
-
Filters
-
Waterfall boxes
-
Streams
-
Other external components
If any of those areas are leaking, they can cause the pond level to drop even when the main pond liner is perfectly intact.
Turning off the pump removes those components from the equation.
Now watch the water level.
If the pond continues losing water with the pump OFF:
The leak is likely within the main pond area.
If the pond stops losing water with the pump OFF:
The problem is more likely somewhere in the operating system, such as the plumbing, filtration, waterfall or stream.
One simple test has now eliminated a large portion of the pond from your search.
Step 2: If the Water Keeps Dropping, Let It Find the Leak Level
If the pond continues losing water after the pump is turned off, resist the urge to immediately refill it.
Instead, monitor the water level.
A leak below the waterline can continue draining the pond until the water reaches approximately the same elevation as the opening. Once the water drops below that point, the leaking should slow significantly or stop.
Think about a hole in the side of a water bottle.
Water above the hole escapes. Once the water level reaches the hole, there is no longer water above it to flow through the opening.
A lined pond can behave similarly.
When the pond level stabilizes, you still may not know exactly where the leak is, but you have dramatically narrowed the search.
Instead of inspecting every square foot of liner from top to bottom, begin examining the pond around the elevation where the water stopped.
Look for:
-
Punctures
-
Tears
-
Damaged liner
-
Settled edges
-
Roots
-
Vegetation
-
Areas where water may be escaping behind rocks
Check the entire perimeter at that elevation rather than assuming the leak will be in the first suspicious area you find.
Step 3: Check for Collapsed Edges
Because collapsed edges are such a common source of water loss, they deserve another look during the troubleshooting process.
Walk slowly around the pond and compare the liner edge with the normal operating water level.
Look for areas where:
-
Soil has settled
-
Large rocks have shifted
-
Liner has been pulled downward
-
Water is reaching or passing over the liner edge
-
The ground outside the pond remains unusually wet
Streams deserve particular attention because they contain more edges and often include multiple layers of rock and liner.
A collapsed stream edge can send a surprising amount of water into the surrounding landscape without making the source immediately obvious.
Step 4: If the Water Stops Dropping, Follow the Plumbing
What if you shut the pump off and the pond level stays exactly where it is? That is useful information.
If the pond only loses water while the pump is operating, begin tracing the path the water takes after it leaves the pond. Start near the pump or skimmer and work upstream through the system.
Inspect:
-
Plumbing connections
-
Fittings
-
Filters
-
Bead filters or other external filtration
-
Waterfall boxes
-
Streams
-
Return lines
Look for visible dripping as well as damp soil or areas that stay wetter than the surrounding landscape.
Remember that a small plumbing leak may not create an obvious puddle. Water can travel along pipes or disappear into soil before you ever see it.
Working through the system in order helps prevent you from jumping randomly between possible causes.
Step 5: Check the Waterfall and Stream
Streams can be particularly challenging because the leak may be located anywhere along their length.
A 50-foot stream creates a lot of ground to inspect. Start with the simple clues. Look for wet areas alongside the stream, shifted rocks, settled liner edges or places where water may be splashing outside the intended channel.
If nothing is obvious, divide the stream into smaller sections. Using additional tubing or temporarily redirecting the plumbing, you can test shorter portions of the stream individually. Instead of troubleshooting one 50-foot stream, you might test the first 10 feet, then 20 feet, then 30 feet.
Once water loss begins during one of those tests, you have narrowed the problem to a much smaller area.
This approach can save considerable time compared with dismantling an entire stream in search of one leak.
Don't Forget Liner Overlaps
Some water features use overlapping pieces of liner, particularly where a stream or waterfall connects to the main pond.
When properly installed, the upper liner overlaps the lower liner similar to shingles on a roof. Water naturally flows over the overlap rather than traveling backward underneath it.
Problems can occur when there is not enough overlap, the liner shifts or water finds a path behind the upper section.
If your pond or stream contains an overlapping liner connection and the leak appears to be in that area, inspect the overlap before assuming you have a puncture.
How Do You Repair a Pond Liner Leak?
Once you have actually located a puncture, the repair may be much less intimidating than finding it.
The correct repair method depends on the type of liner installed in the pond. EPDM and woven coated poly liners, for example, require compatible repair materials.
For many small punctures, a liner patch kit is the practical solution.
A typical repair involves cleaning and preparing the damaged area before applying the appropriate primer, tape or patch material according to the manufacturer's instructions.
The key is knowing what type of liner you have before choosing a repair product.
A small puncture does not necessarily mean the entire pond needs to be relined.
Large areas of damage are different. If the liner is extensively torn or deteriorated, patching may no longer be practical and a larger section may need to be repaired or replaced.
Can Dogs Puncture a Pond Liner?
This is a common concern for pond owners with pets.
Quality 45 mil EPDM pond liner, like our DuraLiner is durable material. Normal activity from a dog around a properly constructed pond does not automatically mean the liner will be punctured, particularly when rock and other materials protect much of the liner.
If your dog regularly swims, plays or walks in the pond and you want some extra peace of mind, an additional layer of underlayment can be placed over the liner in areas the dog can access. This provides another layer of protection between their paws and the liner.
That does not mean the liner is indestructible. Sharp objects, aggressive digging, chewing or other unusual conditions can still cause damage.
If your dog regularly enjoys the pond and you suddenly begin losing water, however, do not automatically blame the dog. Start with the same troubleshooting process you would use for any other pond leak. Check the easy and common causes before assuming the liner has been punctured.
What About an Earthen Pond That Is Losing Water?
Leak detection becomes more complicated when there is no liner. Earthen ponds interact with the surrounding soil and groundwater, which means changes in the water table can affect the pond level.
Like a lined pond, an earthen pond may eventually drop to a level and stabilize. Unlike a lined pond, that stabilization point does not necessarily tell you exactly where water is escaping. This is because the surrounding water table may be influencing the level.
Large earthen ponds can also involve regulatory and environmental considerations, particularly when they connect to other bodies of water.
If an established earthen pond that previously held water begins losing a significant amount, professional evaluation may be the best next step. Depending on the location and water body, local natural-resource or environmental agencies may also need to be involved.
Finding a Pond Leak Is a Process of Elimination
A leaking pond is frustrating, especially when the source is hidden beneath rocks, landscaping or dozens of feet of stream. The solution is rarely to start tearing everything apart, rather just begin with what you know.
Determine whether the water loss is beyond normal evaporation and splash. Inspect the perimeter for wet areas, settled edges and vegetation. Turn off the pump and see what happens.
If the water continues dropping, let it stabilize and inspect the main pond around that elevation. If it stops dropping, follow the operating system from the pond through the plumbing, filtration, waterfall and stream. Each test should make the search area smaller.
The goal is not to guess where your pond is leaking. It is to systematically eliminate the places where it isn't. Once you have isolated the problem, the actual repair may be much simpler than you expected.
